MSI-P442-K/I - PC/104 Thermocouple Input Board (12 Ch K Type T/C + 4 Ch of Analog
Input)
MSI-P442-K/O - PC/104 Thermocouple Input Board (12 Ch K Type T/C  + 1 Analog Output)
MSI-P442-K - PC/104 Thermocouple Input Board (12 Ch K Type T/C )
MSI-P442-K-8 - PC/104 Thermocouple Input Board (8 Ch K Type T/C )
MSI-P440-K/A - PC/104 Thermocouple Input Board (8 Ch K Type T/C & 8 Ch of Analog
Input)

MSI-P440-K - PC/104 Thermocouple Input Board (8 Ch K Type T/C)
MSI-P910 - PC/104 Analog Input Terminal Board (Terminal Strip Input Connections for 8 ro 16 channels)
MSI-P442-K/I/O - PC/104 Thermocouple Input Board (12 Ch K Type T/C + 4 Ch of Analog Input + 1 Analog Output)
Thermocouple models provide up to 12 channels of K-Type thermocouples with optional 4 channels (12- bit) of Analog Input and 1 channel (12-bit) of Analog Output. The thermocouple inputs are conditioned by Analog Devices AD597 devices which provide built-in ice point compensation with temperature proportional operation of 10 mV/°C in the temperature range of -200°C to 1000°C.
Microcomputer Systems, Inc.
PC/104 Thermocouple Input Boards for Temperature Measurement
